Scott Addict Gravel 20
$4,299.99
Details
The SCOTT Addict Gravel 20 will get you wherever you’re going, no matter what the trail throws at you. More progressive, more control, and more mounts mean this adventure-ready machine is your ticket to getting out there. Find yourself, get lost.
Key Features
- Addict Gravel HMF Carbon Fork
- Addict Gravel HMF Carbon Frame
- SRAM RIVAL AXS Disc 24-Speed
- Syncros Capital X40 Carbon
- Schwalbe G-One Bite Tires
| Frame Size | XS/49 | S/52 | M/54 | L/56 | XL/58 |
|---|---|---|---|---|---|
| Head Tube Angle (degrees) | 70 | 70 | 71 | 71 | 71 |
| Head Tube Length (mm/in) | 95.0 / 3.7 | 122.0 / 4.8 | 140.0 / 5.5 | 166.0 / 6.5 | 187.0 / 7.4 |
| Top Tube Horizontal (mm/in) | 518.0 / 20.4 | 534.5 / 21.0 | 554.5 / 21.8 | 578.5 / 22.8 | 592.5 / 23.3 |
| Standover Height (mm/in) | 759.0 / 29.9 | 786.0 / 30.9 | 807.0 / 31.8 | 828.0 / 32.6 | 847.0 / 33.3 |
| Bottom Bracket Offset (mm/in) | -71.0 / -2.8 | -71.0 / -2.8 | -71.0 / -2.8 | -71.0 / -2.8 | -71.0 / -2.8 |
| Bottom Bracket Height (mm/in) | 283.0 / 11.1 | 283.0 / 11.1 | 283.0 / 11.1 | 283.0 / 11.1 | 283.0 / 11.1 |
| Wheelbase (mm/in) | 1,009.4 / 39.7 | 1,022.9 / 40.3 | 1,029.2 / 40.5 | 1,048.7 / 41.3 | 1,063.5 / 41.9 |
| BB Center to Top Tube Center (mm/in) | 447.0 / 17.6 | 477.0 / 18.8 | 498.0 / 19.6 | 516.0 / 20.3 | 536.0 / 21.1 |
| BB Center to Top of Seat Tube (mm/in) | 477.0 / 18.8 | 507.0 / 20.0 | 528.0 / 20.8 | 546.0 / 21.5 | 566.0 / 22.3 |
| Seat Tube Angle (degrees) | 74.5 | 74 | 73.5 | 73 | 73 |
| Chainstay Length (mm/in) | 425.0 / 16.7 | 425.0 / 16.7 | 425.0 / 16.7 | 425.0 / 16.7 | 425.0 / 16.7 |
| Reach (mm/in) | 374.1 / 14.7 | 378.4 / 14.9 | 387.1 / 15.2 | 398.2 / 15.7 | 406.1 / 16.0 |
| Stack (mm/in) | 519.0 / 20.4 | 544.4 / 21.4 | 565.3 / 22.3 | 589.9 / 23.2 | 609.7 / 24.0 |
| Stem Length (mm/in) | 83.0 / 3.3 | 93.0 / 3.7 | 103.0 / 4.1 | 103.0 / 4.1 | 113.0 / 4.4 |
| Frame Size | Body Height (cm) | Body Height (in) |
|---|---|---|
| XSS / XS / S | < 165 | < 65 |
| XS / S / M | 165 - 175 | 65 - 69 |
| M / L | 175 - 185 | 69 - 73 |
| L / XL / XXL | 185 - 195 | 73 - 77 |
| XL / XXL | > 195 | > 77 |
Specs
| Frame | Addict Gravel HMF Carbon Gravel geometry / Replaceable Derailleur Hanger Internal cable routing Syncros fender kit ready |
|---|---|
| Fork | Addict Gravel HMF Flatmount Disc 1 1/4"-1 1/2" Eccentric Carbon steere |
| Wheels | Syncros Capital X40 Carbon 24 Front / 24 Rear Syncros SL Axle / Removable Lever with Tool |
| Tires | Schwalbe G-One Bite Performance 700x45C |
| Bottom Bracket | SRAM DUB PF ROAD 86.5 |
| Crankset | SRAM RIVAL Crankset 46/33 |
| Shifters | SRAM RIVAL eTap AXS HRD Shift-Brake System |
| Front Derailleur | SRAM RIVAL eTap AXS Electronic Shift System |
| Rear Derailleur | SRAM RIVAL eTap AXS 24 Speed Electronic Shift System |
| Cassette/Freewheel | SRAM RIVAL XG1250 10-36 |
| Chain | SRAM RIVAL |
| Brakes | SRAM RIVAL eTap AXS HRD Shift-Brake System |
| Rotors | SRAM Paceline rotor 160/F and 160/R |
| Handlebars | Syncros Creston 2.0 X Alloy 31.8mm |
| Stem | Syncros RR2.0 1 1/4" / four Bolt 31.8mm |
| Headset | Acros AIF-1134 |
| Seatpost | Syncros SP-R101-CF |
| Saddle | Syncros Tofino Regular 2.0 Cutout |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Petrol Black / Large / 700c | 07616185210320 | 4232267315010 | SCO33139359L |
